USB2.0  : caméras cartes miniatures / endoscopes USB OEM



Caméras USB2.0 embarquées, compatibles UVC, capteurs CMOS de 1/4" 5Mp à 1/18" 160k, différents formats de cartes et PCB : de 22x26mm à un diamètre de 1,4mm pour les applications d'endoscopie.

module camera oem miniature

Produits associés :

module camera oem miniature

Module camera carte 5Mp

  • Compact size 5Mp board camera
  • 1/4" CMOS sensor 1.4um
  • 2592x1944 @ 15fps
  • 1920x1080 @ 30fps
  • USB2.0 (UVC)
  • 22x26mm
Option :
  • built-in AF lens
  • standard M12 lens
  • fisheye lens
autofocus usb camera
camera carte usb miniature
camera fisheye usb

module camera oem miniature

Module camera axiale 5Mp

  • Compact size 5Mp probe camera
  • 1/4" CMOS sensor 1.4um
  • 2592x1944 @ 15fps
  • 1920x1080 @ 30fps
  • USB2.0 (UVC)
  • Diam14x26mm
Option :
  • built-in AF lens
  • AF lens + LED lighting
  • standard M12 lens
  • fisheye lens
  • board level w/o lens (Diam18 mm)
camera axiale usb autofocus
camera usb anneau led
camera usb m12
camera usb fisheye
camera carte usb axiale

module camera oem miniature

Module camera carte miniature sideview 2mP

  • Compact size / low depth in the optical axis
  • Sideview camera
  • 1/6" CMOS sensor 1.4um
  • 1920x1080 @ 30fps MJPEG
  • 640x480 @ 30fps YUV
  • USB2.0 (UVC)
  • 3.2x7x22mm
Option :
  • microphone
  • LED
camera usb sideview autofocus


module camera oem miniature endoscope

module camera compact full hd pour endoscope

  • Compact size
  • 1/6" CMOS sensor 1.4um
  • 1920x1080 @ 15 to 30fps MJPEG
  • USB2.0 (UVC)
Options :
  • Front or side view
  • USB connector choice
  • 4.9 to 14mm diameter head
  • 77°, 91° or 158° FOV
  • LED
  • GPIO pin (snapshot, freeze)
endoscope usb
camera oem endoscope
camera usb diametre 14mm


camera compacte endoscope

module camera miniature pour endoscope

  • Ultra miniature size 1.4mm diameter
  • 1/18" CMOS sensor 1.75um
  • 400x400 @ 30fps
Options :
  • USB2.0 (UVC) or analog CVBS interface
  • 1.4mm diameter round PCB module
  • 1.05mm square PCB module
  • 1.6mm diameter packaged head
  • 2.5mm diameter packaged head with LEDs
1mm endoscope usb
